Open CASCADE Technology Reference Manual 8.0.0
|
A base class of Modification's from ShapeCustom. Implements message sending mechanism. More...
#include <ShapeCustom_Modification.hxx>
Public Member Functions | |
| virtual void | SetMsgRegistrator (const occ::handle< ShapeExtend_BasicMsgRegistrator > &msgreg) |
| Sets message registrator. | |
| occ::handle< ShapeExtend_BasicMsgRegistrator > | MsgRegistrator () const |
| Returns message registrator. | |
| void | SendMsg (const TopoDS_Shape &shape, const Message_Msg &message, const Message_Gravity gravity=Message_Info) const |
| Sends a message to be attached to the shape. Calls corresponding message of message registrator. | |
 Public Member Functions inherited from BRepTools_Modification | |
| virtual bool | NewSurface (const TopoDS_Face &F, occ::handle< Geom_Surface > &S, TopLoc_Location &L, double &Tol, bool &RevWires, bool &RevFace)=0 |
| Returns true if the face, F, has been modified. If the face has been modified: | |
| virtual bool | NewTriangulation (const TopoDS_Face &F, occ::handle< Poly_Triangulation > &T) |
| Returns true if the face has been modified according to changed triangulation. If the face has been modified: | |
| virtual bool | NewCurve (const TopoDS_Edge &E, occ::handle< Geom_Curve > &C, TopLoc_Location &L, double &Tol)=0 |
| Returns true if the edge, E, has been modified. If the edge has been modified: | |
| virtual bool | NewPolygon (const TopoDS_Edge &E, occ::handle< Poly_Polygon3D > &P) |
| Returns true if the edge has been modified according to changed polygon. If the edge has been modified: | |
| virtual bool | NewPolygonOnTriangulation (const TopoDS_Edge &E, const TopoDS_Face &F, occ::handle< Poly_PolygonOnTriangulation > &P) |
| Returns true if the edge has been modified according to changed polygon on triangulation. If the edge has been modified: | |
| virtual bool | NewPoint (const TopoDS_Vertex &V, gp_Pnt &P, double &Tol)=0 |
| Returns true if the vertex V has been modified. If V has been modified: | |
| virtual bool | NewCurve2d (const TopoDS_Edge &E, const TopoDS_Face &F, const TopoDS_Edge &NewE, const TopoDS_Face &NewF, occ::handle< Geom2d_Curve > &C, double &Tol)=0 |
| Returns true if the edge, E, has a new curve on surface on the face, F. If a new curve exists: | |
| virtual bool | NewParameter (const TopoDS_Vertex &V, const TopoDS_Edge &E, double &P, double &Tol)=0 |
| Returns true if the vertex V has a new parameter on the edge E. If a new parameter exists: | |
| virtual GeomAbs_Shape | Continuity (const TopoDS_Edge &E, const TopoDS_Face &F1, const TopoDS_Face &F2, const TopoDS_Edge &NewE, const TopoDS_Face &NewF1, const TopoDS_Face &NewF2)=0 |
| Returns the continuity of <NewE> between <NewF1> and <NewF2>. <NewE> is the new edge created from <E>. <NewF1> (resp. <NewF2>) is the new face created from <F1> (resp. <F2>). | |
| Public Member Functions inherited from Standard_Transient | |
| Standard_Transient () | |
| Empty constructor. | |
| Standard_Transient (const Standard_Transient &) | |
| Copy constructor – does nothing. | |
| Standard_Transient & | operator= (const Standard_Transient &) |
| Assignment operator, needed to avoid copying reference counter. | |
| virtual | ~Standard_Transient ()=default |
| Destructor must be virtual. | |
| virtual const opencascade::handle< Standard_Type > & | DynamicType () const |
| Returns a type descriptor about this object. | |
| bool | IsInstance (const opencascade::handle< Standard_Type > &theType) const |
| Returns a true value if this is an instance of Type. | |
| bool | IsInstance (const char *const theTypeName) const |
| Returns a true value if this is an instance of TypeName. | |
| bool | IsKind (const opencascade::handle< Standard_Type > &theType) const |
| Returns true if this is an instance of Type or an instance of any class that inherits from Type. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| bool | IsKind (const char *const theTypeName) const |
| Returns true if this is an instance of TypeName or an instance of any class that inherits from TypeName. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Transient * | This () const |
| Returns non-const pointer to this object (like const_cast). For protection against creating handle to objects allocated in stack or call from constructor, it will raise exception Standard_ProgramError if reference counter is zero. | |
| int | GetRefCount () const noexcept |
| Get the reference counter of this object. | |
| void | IncrementRefCounter () noexcept |
| Increments the reference counter of this object. Uses relaxed memory ordering since incrementing only requires atomicity, not synchronization with other memory operations. | |
| int | DecrementRefCounter () noexcept |
| Decrements the reference counter of this object; returns the decremented value. Uses release ordering for the decrement to ensure all writes to the object are visible before the count reaches zero. An acquire fence is added only when the count reaches zero, ensuring proper synchronization before deletion. This is more efficient than using acq_rel for every decrement. | |
| virtual void | Delete () const |
| Memory deallocator for transient classes. | |
Additional Inherited Members | |
| Public Types inherited from Standard_Transient | |
| typedef void | base_type |
| Returns a type descriptor about this object. | |
| Static Public Member Functions inherited from Standard_Transient | |
| static constexpr const char * | get_type_name () |
| Returns a type descriptor about this object. | |
| static const opencascade::handle< Standard_Type > & | get_type_descriptor () |
| Returns type descriptor of Standard_Transient class. | |
A base class of Modification's from ShapeCustom. Implements message sending mechanism.
| occ::handle< ShapeExtend_BasicMsgRegistrator > ShapeCustom_Modification::MsgRegistrator | ( | ) | const |
Returns message registrator.
| void ShapeCustom_Modification::SendMsg | ( | const TopoDS_Shape & | shape, |
| const Message_Msg & | message, | ||
| const Message_Gravity | gravity = Message_Info ) const |
Sends a message to be attached to the shape. Calls corresponding message of message registrator.
|
virtual |
Sets message registrator.
