Open CASCADE Technology Reference Manual 8.0.0
|
retrieval driver of a Part document More...
#include <StdLDrivers_DocumentRetrievalDriver.hxx>
Public Member Functions | |
| void | Read (const TCollection_ExtendedString &theFileName, const occ::handle< CDM_Document > &theNewDocument, const occ::handle< CDM_Application > &theApplication, const occ::handle< PCDM_ReaderFilter > &theFilter=occ::handle< PCDM_ReaderFilter >(), const Message_ProgressRange &theRange=Message_ProgressRange()) override |
| Retrieve the content of a file into a new document. | |
| void | Read (Standard_IStream &theIStream, const occ::handle< Storage_Data > &theStorageData, const occ::handle< CDM_Document > &theDoc, const occ::handle< CDM_Application > &theApplication, const occ::handle< PCDM_ReaderFilter > &theFilter=occ::handle< PCDM_ReaderFilter >(), const Message_ProgressRange &theRange=Message_ProgressRange()) override |
| Override pure virtual method (raises exception Standard_NotImplemented) | |
 Public Member Functions inherited from PCDM_RetrievalDriver | |
| void | SetFormat (const TCollection_ExtendedString &aformat) |
| TCollection_ExtendedString | GetFormat () const |
| Public Member Functions inherited from PCDM_Reader | |
| PCDM_ReaderStatus | GetStatus () const |
| Public Member Functions inherited from Standard_Transient | |
| Standard_Transient () | |
| Empty constructor. | |
| Standard_Transient (const Standard_Transient &) | |
| Copy constructor – does nothing. | |
| Standard_Transient & | operator= (const Standard_Transient &) |
| Assignment operator, needed to avoid copying reference counter. | |
| virtual | ~Standard_Transient ()=default |
| Destructor must be virtual. | |
| virtual const opencascade::handle< Standard_Type > & | DynamicType () const |
| Returns a type descriptor about this object. | |
| bool | IsInstance (const opencascade::handle< Standard_Type > &theType) const |
| Returns a true value if this is an instance of Type. | |
| bool | IsInstance (const char *const theTypeName) const |
| Returns a true value if this is an instance of TypeName. | |
| bool | IsKind (const opencascade::handle< Standard_Type > &theType) const |
| Returns true if this is an instance of Type or an instance of any class that inherits from Type. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| bool | IsKind (const char *const theTypeName) const |
| Returns true if this is an instance of TypeName or an instance of any class that inherits from TypeName. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Transient * | This () const |
| Returns non-const pointer to this object (like const_cast). For protection against creating handle to objects allocated in stack or call from constructor, it will raise exception Standard_ProgramError if reference counter is zero. | |
| int | GetRefCount () const noexcept |
| Get the reference counter of this object. | |
| void | IncrementRefCounter () noexcept |
| Increments the reference counter of this object. Uses relaxed memory ordering since incrementing only requires atomicity, not synchronization with other memory operations. | |
| int | DecrementRefCounter () noexcept |
| Decrements the reference counter of this object; returns the decremented value. Uses release ordering for the decrement to ensure all writes to the object are visible before the count reaches zero. An acquire fence is added only when the count reaches zero, ensuring proper synchronization before deletion. This is more efficient than using acq_rel for every decrement. | |
| virtual void | Delete () const |
| Memory deallocator for transient classes. | |
Protected Member Functions | |
| virtual void | bindTypes (StdObjMgt_MapOfInstantiators &theMap) |
| Register types. | |
Additional Inherited Members | |
| Public Types inherited from Standard_Transient | |
| typedef void | base_type |
| Returns a type descriptor about this object. | |
| Static Public Member Functions inherited from PCDM_RetrievalDriver | |
| static int | DocumentVersion (const TCollection_ExtendedString &theFileName, const occ::handle< Message_Messenger > &theMsgDriver) |
| static int | ReferenceCounter (const TCollection_ExtendedString &theFileName, const occ::handle< Message_Messenger > &theMsgDriver) |
| Static Public Member Functions inherited from Standard_Transient | |
| static constexpr const char * | get_type_name () |
| Returns a type descriptor about this object. | |
| static const opencascade::handle< Standard_Type > & | get_type_descriptor () |
| Returns type descriptor of Standard_Transient class. | |
| Protected Attributes inherited from PCDM_Reader | |
| PCDM_ReaderStatus | myReaderStatus |
retrieval driver of a Part document
|
protectedvirtual |
Register types.
Reimplemented in StdDrivers_DocumentRetrievalDriver.
|
overridevirtual |
Retrieve the content of a file into a new document.
Implements PCDM_Reader.
|
overridevirtual |
Override pure virtual method (raises exception Standard_NotImplemented)
Implements PCDM_Reader.
