Open CASCADE Technology Reference Manual 8.0.0
|
Representation of STEP entity TessellatedPointSet. More...
#include <StepVisual_TessellatedPointSet.hxx>
Public Member Functions | |
| StepVisual_TessellatedPointSet () | |
| default constructor | |
| void | Init (const occ::handle< TCollection_HAsciiString > &theRepresentationItem_Name, const occ::handle< StepVisual_CoordinatesList > &theCoordinates, const occ::handle< NCollection_HArray1< int > > &thePointList) |
| Initialize all fields (own and inherited) | |
| occ::handle< StepVisual_CoordinatesList > | Coordinates () const |
| Returns field Coordinates. | |
| void | SetCoordinates (const occ::handle< StepVisual_CoordinatesList > &theCoordinates) |
| Sets field Coordinates. | |
| occ::handle< NCollection_HArray1< int > > | PointList () const |
| Returns field PointList. | |
| void | SetPointList (const occ::handle< NCollection_HArray1< int > > &thePointList) |
| Sets field PointList. | |
| int | NbPointList () const |
| Returns number of PointList. | |
| int | PointListValue (const int theNum) const |
| Returns value of PointList by its num. | |
 Public Member Functions inherited from StepVisual_TessellatedItem | |
| StepVisual_TessellatedItem () | |
| Returns a DraughtingCalloutElement select type. | |
| Public Member Functions inherited from StepGeom_GeometricRepresentationItem | |
| StepGeom_GeometricRepresentationItem () | |
| Returns a GeometricRepresentationItem. | |
| Public Member Functions inherited from StepRepr_RepresentationItem | |
| StepRepr_RepresentationItem () | |
| Returns a RepresentationItem. | |
| void | Init (const occ::handle< TCollection_HAsciiString > &aName) |
| void | SetName (const occ::handle< TCollection_HAsciiString > &aName) |
| occ::handle< TCollection_HAsciiString > | Name () const |
| Public Member Functions inherited from Standard_Transient | |
| Standard_Transient () | |
| Empty constructor. | |
| Standard_Transient (const Standard_Transient &) | |
| Copy constructor – does nothing. | |
| Standard_Transient & | operator= (const Standard_Transient &) |
| Assignment operator, needed to avoid copying reference counter. | |
| virtual | ~Standard_Transient ()=default |
| Destructor must be virtual. | |
| virtual const opencascade::handle< Standard_Type > & | DynamicType () const |
| Returns a type descriptor about this object. | |
| bool | IsInstance (const opencascade::handle< Standard_Type > &theType) const |
| Returns a true value if this is an instance of Type. | |
| bool | IsInstance (const char *const theTypeName) const |
| Returns a true value if this is an instance of TypeName. | |
| bool | IsKind (const opencascade::handle< Standard_Type > &theType) const |
| Returns true if this is an instance of Type or an instance of any class that inherits from Type. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| bool | IsKind (const char *const theTypeName) const |
| Returns true if this is an instance of TypeName or an instance of any class that inherits from TypeName. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Transient * | This () const |
| Returns non-const pointer to this object (like const_cast). For protection against creating handle to objects allocated in stack or call from constructor, it will raise exception Standard_ProgramError if reference counter is zero. | |
| int | GetRefCount () const noexcept |
| Get the reference counter of this object. | |
| void | IncrementRefCounter () noexcept |
| Increments the reference counter of this object. Uses relaxed memory ordering since incrementing only requires atomicity, not synchronization with other memory operations. | |
| int | DecrementRefCounter () noexcept |
| Decrements the reference counter of this object; returns the decremented value. Uses release ordering for the decrement to ensure all writes to the object are visible before the count reaches zero. An acquire fence is added only when the count reaches zero, ensuring proper synchronization before deletion. This is more efficient than using acq_rel for every decrement. | |
| virtual void | Delete () const |
| Memory deallocator for transient classes. | |
Additional Inherited Members | |
| Public Types inherited from Standard_Transient | |
| typedef void | base_type |
| Returns a type descriptor about this object. | |
| Static Public Member Functions inherited from Standard_Transient | |
| static constexpr const char * | get_type_name () |
| Returns a type descriptor about this object. | |
| static const opencascade::handle< Standard_Type > & | get_type_descriptor () |
| Returns type descriptor of Standard_Transient class. | |
Representation of STEP entity TessellatedPointSet.
| StepVisual_TessellatedPointSet::StepVisual_TessellatedPointSet | ( | ) |
default constructor
| occ::handle< StepVisual_CoordinatesList > StepVisual_TessellatedPointSet::Coordinates | ( | ) | const |
Returns field Coordinates.
| void StepVisual_TessellatedPointSet::Init | ( | const occ::handle< TCollection_HAsciiString > & | theRepresentationItem_Name, |
| const occ::handle< StepVisual_CoordinatesList > & | theCoordinates, | ||
| const occ::handle< NCollection_HArray1< int > > & | thePointList ) |
Initialize all fields (own and inherited)
| int StepVisual_TessellatedPointSet::NbPointList | ( | ) | const |
Returns number of PointList.
| occ::handle< NCollection_HArray1< int > > StepVisual_TessellatedPointSet::PointList | ( | ) | const |
Returns field PointList.
Returns value of PointList by its num.
| void StepVisual_TessellatedPointSet::SetCoordinates | ( | const occ::handle< StepVisual_CoordinatesList > & | theCoordinates | ) |
Sets field Coordinates.
| void StepVisual_TessellatedPointSet::SetPointList | ( | const occ::handle< NCollection_HArray1< int > > & | thePointList | ) |
Sets field PointList.
