Open CASCADE Technology Reference Manual 8.0.0
|
Representation of STEP entity TessellatedWire. More...
#include <StepVisual_TessellatedWire.hxx>
Public Member Functions | |
| StepVisual_TessellatedWire () | |
| default constructor | |
| void | Init (const occ::handle< TCollection_HAsciiString > &theRepresentationItem_Name, const occ::handle< NCollection_HArray1< StepVisual_TessellatedEdgeOrVertex > > &theItems, const bool theHasGeometricModelLink, const StepVisual_PathOrCompositeCurve &theGeometricModelLink) |
| Initialize all fields (own and inherited) | |
| occ::handle< NCollection_HArray1< StepVisual_TessellatedEdgeOrVertex > > | Items () const |
| Returns field Items. | |
| void | SetItems (const occ::handle< NCollection_HArray1< StepVisual_TessellatedEdgeOrVertex > > &theItems) |
| Sets field Items. | |
| int | NbItems () const |
| Returns number of Items. | |
| const StepVisual_TessellatedEdgeOrVertex & | ItemsValue (const int theNum) const |
| Returns value of Items by its num. | |
| StepVisual_PathOrCompositeCurve | GeometricModelLink () const |
| Returns field GeometricModelLink. | |
| void | SetGeometricModelLink (const StepVisual_PathOrCompositeCurve &theGeometricModelLink) |
| Sets field GeometricModelLink. | |
| bool | HasGeometricModelLink () const |
| Returns True if optional field GeometricModelLink is defined. | |
 Public Member Functions inherited from StepVisual_TessellatedItem | |
| StepVisual_TessellatedItem () | |
| Returns a DraughtingCalloutElement select type. | |
| Public Member Functions inherited from StepGeom_GeometricRepresentationItem | |
| StepGeom_GeometricRepresentationItem () | |
| Returns a GeometricRepresentationItem. | |
| Public Member Functions inherited from StepRepr_RepresentationItem | |
| StepRepr_RepresentationItem () | |
| Returns a RepresentationItem. | |
| void | Init (const occ::handle< TCollection_HAsciiString > &aName) |
| void | SetName (const occ::handle< TCollection_HAsciiString > &aName) |
| occ::handle< TCollection_HAsciiString > | Name () const |
| Public Member Functions inherited from Standard_Transient | |
| Standard_Transient () | |
| Empty constructor. | |
| Standard_Transient (const Standard_Transient &) | |
| Copy constructor – does nothing. | |
| Standard_Transient & | operator= (const Standard_Transient &) |
| Assignment operator, needed to avoid copying reference counter. | |
| virtual | ~Standard_Transient ()=default |
| Destructor must be virtual. | |
| virtual const opencascade::handle< Standard_Type > & | DynamicType () const |
| Returns a type descriptor about this object. | |
| bool | IsInstance (const opencascade::handle< Standard_Type > &theType) const |
| Returns a true value if this is an instance of Type. | |
| bool | IsInstance (const char *const theTypeName) const |
| Returns a true value if this is an instance of TypeName. | |
| bool | IsKind (const opencascade::handle< Standard_Type > &theType) const |
| Returns true if this is an instance of Type or an instance of any class that inherits from Type. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| bool | IsKind (const char *const theTypeName) const |
| Returns true if this is an instance of TypeName or an instance of any class that inherits from TypeName. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Transient * | This () const |
| Returns non-const pointer to this object (like const_cast). For protection against creating handle to objects allocated in stack or call from constructor, it will raise exception Standard_ProgramError if reference counter is zero. | |
| int | GetRefCount () const noexcept |
| Get the reference counter of this object. | |
| void | IncrementRefCounter () noexcept |
| Increments the reference counter of this object. Uses relaxed memory ordering since incrementing only requires atomicity, not synchronization with other memory operations. | |
| int | DecrementRefCounter () noexcept |
| Decrements the reference counter of this object; returns the decremented value. Uses release ordering for the decrement to ensure all writes to the object are visible before the count reaches zero. An acquire fence is added only when the count reaches zero, ensuring proper synchronization before deletion. This is more efficient than using acq_rel for every decrement. | |
| virtual void | Delete () const |
| Memory deallocator for transient classes. | |
Additional Inherited Members | |
| Public Types inherited from Standard_Transient | |
| typedef void | base_type |
| Returns a type descriptor about this object. | |
| Static Public Member Functions inherited from Standard_Transient | |
| static constexpr const char * | get_type_name () |
| Returns a type descriptor about this object. | |
| static const opencascade::handle< Standard_Type > & | get_type_descriptor () |
| Returns type descriptor of Standard_Transient class. | |
Representation of STEP entity TessellatedWire.
| StepVisual_TessellatedWire::StepVisual_TessellatedWire | ( | ) |
default constructor
| StepVisual_PathOrCompositeCurve StepVisual_TessellatedWire::GeometricModelLink | ( | ) | const |
Returns field GeometricModelLink.
| bool StepVisual_TessellatedWire::HasGeometricModelLink | ( | ) | const |
Returns True if optional field GeometricModelLink is defined.
| void StepVisual_TessellatedWire::Init | ( | const occ::handle< TCollection_HAsciiString > & | theRepresentationItem_Name, |
| const occ::handle< NCollection_HArray1< StepVisual_TessellatedEdgeOrVertex > > & | theItems, | ||
| const bool | theHasGeometricModelLink, | ||
| const StepVisual_PathOrCompositeCurve & | theGeometricModelLink ) |
Initialize all fields (own and inherited)
| occ::handle< NCollection_HArray1< StepVisual_TessellatedEdgeOrVertex > > StepVisual_TessellatedWire::Items | ( | ) | const |
Returns field Items.
| const StepVisual_TessellatedEdgeOrVertex & StepVisual_TessellatedWire::ItemsValue | ( | const int | theNum | ) | const |
Returns value of Items by its num.
| int StepVisual_TessellatedWire::NbItems | ( | ) | const |
Returns number of Items.
| void StepVisual_TessellatedWire::SetGeometricModelLink | ( | const StepVisual_PathOrCompositeCurve & | theGeometricModelLink | ) |
Sets field GeometricModelLink.
| void StepVisual_TessellatedWire::SetItems | ( | const occ::handle< NCollection_HArray1< StepVisual_TessellatedEdgeOrVertex > > & | theItems | ) |
Sets field Items.
