Open CASCADE Technology Reference Manual 8.0.0
|
Redefines BoxSet to use the Linear builder by default. More...
#include <BOPTools_BoxTree.hxx>
Public Member Functions | |
Constructors | |
Empty constructor for use the default BVH_Builder | |
| BOPTools_BoxSet (const opencascade::handle< BVH_Builder< NumType, Dimension > > &theBuilder=nullptr) | |
 Public Member Functions inherited from BVH_BoxSet< NumType, Dimension, DataType > | |
| BVH_BoxSet () | |
| Constructor for usage the custom BVH builder. | |
| BVH_BoxSet (const opencascade::handle< BVH_Builder< NumType, Dimension > > &theBuilder) | |
| Constructor for usage the custom BVH builder. | |
| virtual void | SetSize (const size_t theSize) |
| virtual void | Add (const DataType &theElement, const BVH_Box< NumType, Dimension > &theBox) |
| void | Build () |
| virtual void | Clear () |
| BVH_Box< NumType, Dimension > | Box (const int theIndex) const override |
| Returns the bounding box with the given index. | |
| double | Center (const int theIndex, const int theAxis) const override |
| Returns centroid position along specified axis. | |
| int | Size () const override |
| Returns the number of boxes. | |
| void | Swap (const int theIndex1, const int theIndex2) override |
| Swaps indices of two specified boxes. | |
| virtual DataType | Element (const int theIndex) const |
| Returns the Element with the index theIndex. | |
| Public Member Functions inherited from BVH_PrimitiveSet< NumType, Dimension > | |
| BVH_PrimitiveSet () | |
| Creates set of abstract primitives. | |
| BVH_PrimitiveSet (const opencascade::handle< BVH_Builder< NumType, N > > &theBuilder) | |
| Creates set of abstract primitives. | |
| ~BVH_PrimitiveSet () override | |
| Releases resources of set of abstract primitives. | |
| BVH_Box< NumType, N > | Box () const override |
| Returns AABB of primitive set. | |
| virtual const opencascade::handle< BVH_Tree< NumType, N > > & | BVH () |
| Returns BVH tree (and builds it if necessary). | |
| virtual const opencascade::handle< BVH_Builder< NumType, N > > & | Builder () const |
| Returns the method (builder) used to construct BVH. | |
| virtual void | SetBuilder (const opencascade::handle< BVH_Builder< NumType, N > > &theBuilder) |
| Sets the method (builder) used to construct BVH. | |
| Public Member Functions inherited from BVH_Object< T, N > | |
| BVH_Object ()=default | |
| Creates new abstract geometric object. | |
| ~BVH_Object () override=default | |
| Releases resources of geometric object. | |
| Public Member Functions inherited from BVH_ObjectTransient | |
| virtual const occ::handle< BVH_Properties > & | Properties () const |
| Returns properties of the geometric object. | |
| virtual void | SetProperties (const occ::handle< BVH_Properties > &theProperties) |
| Sets properties of the geometric object. | |
| virtual bool | IsDirty () const |
| Returns TRUE if object state should be updated. | |
| virtual void | MarkDirty () |
| Marks object state as outdated (needs BVH rebuilding). | |
| Public Member Functions inherited from Standard_Transient | |
| Standard_Transient () | |
| Empty constructor. | |
| Standard_Transient (const Standard_Transient &) | |
| Copy constructor – does nothing. | |
| Standard_Transient & | operator= (const Standard_Transient &) |
| Assignment operator, needed to avoid copying reference counter. | |
| virtual | ~Standard_Transient ()=default |
| Destructor must be virtual. | |
| virtual const opencascade::handle< Standard_Type > & | DynamicType () const |
| Returns a type descriptor about this object. | |
| bool | IsInstance (const opencascade::handle< Standard_Type > &theType) const |
| Returns a true value if this is an instance of Type. | |
| bool | IsInstance (const char *const theTypeName) const |
| Returns a true value if this is an instance of TypeName. | |
| bool | IsKind (const opencascade::handle< Standard_Type > &theType) const |
| Returns true if this is an instance of Type or an instance of any class that inherits from Type. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| bool | IsKind (const char *const theTypeName) const |
| Returns true if this is an instance of TypeName or an instance of any class that inherits from TypeName. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Transient * | This () const |
| Returns non-const pointer to this object (like const_cast). For protection against creating handle to objects allocated in stack or call from constructor, it will raise exception Standard_ProgramError if reference counter is zero. | |
| int | GetRefCount () const noexcept |
| Get the reference counter of this object. | |
| void | IncrementRefCounter () noexcept |
| Increments the reference counter of this object. Uses relaxed memory ordering since incrementing only requires atomicity, not synchronization with other memory operations. | |
| int | DecrementRefCounter () noexcept |
| Decrements the reference counter of this object; returns the decremented value. Uses release ordering for the decrement to ensure all writes to the object are visible before the count reaches zero. An acquire fence is added only when the count reaches zero, ensuring proper synchronization before deletion. This is more efficient than using acq_rel for every decrement. | |
| virtual void | Delete () const |
| Memory deallocator for transient classes. | |
| Public Member Functions inherited from BVH_Set< T, N > | |
| BVH_Set ()=default | |
| Creates new abstract set of objects. | |
| virtual | ~BVH_Set ()=default |
| Releases resources of set of objects. | |
Additional Inherited Members | |
| Public Types inherited from Standard_Transient | |
| typedef void | base_type |
| Returns a type descriptor about this object. | |
| Public Types inherited from BVH_Set< T, N > | |
| typedef BVH_Box< T, N > | BVH_BoxNt |
| Static Public Member Functions inherited from Standard_Transient | |
| static constexpr const char * | get_type_name () |
| Returns a type descriptor about this object. | |
| static const opencascade::handle< Standard_Type > & | get_type_descriptor () |
| Returns type descriptor of Standard_Transient class. | |
| Static Public Attributes inherited from BVH_PrimitiveSet< NumType, Dimension > | |
| static const int | MaxTreeDepth |
| Protected Member Functions inherited from BVH_PrimitiveSet< NumType, Dimension > | |
| virtual void | Update () |
| Updates BVH of primitive set. | |
| Protected Member Functions inherited from BVH_ObjectTransient | |
| BVH_ObjectTransient () | |
| Creates new abstract geometric object. | |
| Protected Attributes inherited from BVH_BoxSet< NumType, Dimension, DataType > | |
| NCollection_LinearVector< DataType > | myElements |
| Elements. | |
| NCollection_LinearVector< BVH_Box< NumType, Dimension > > | myBoxes |
| Boxes for the elements. | |
| Protected Attributes inherited from BVH_PrimitiveSet< NumType, Dimension > | |
| opencascade::handle< BVH_Tree< NumType, N > > | myBVH |
| Constructed bottom-level BVH. | |
| opencascade::handle< BVH_Builder< NumType, N > > | myBuilder |
| Builder for bottom-level BVH. | |
| BVH_Box< NumType, N > | myBox |
| Cached bounding box of geometric primitives. | |
| Protected Attributes inherited from BVH_ObjectTransient | |
| bool | myIsDirty |
| Marks internal object state as outdated. | |
| occ::handle< BVH_Properties > | myProperties |
| Generic properties assigned to the object. | |
Redefines BoxSet to use the Linear builder by default.
|
inline |
