1.13.2 define a PinPoint G0+G2 Constraint used to load a Non Linear Plate More...
#include <NLPlate_HPG0G2Constraint.hxx>
Public Member Functions | |
| NLPlate_HPG0G2Constraint (const gp_XY &UV, const gp_XYZ &Value, const Plate_D1 &D1T, const Plate_D2 &D2T) | |
| virtual Standard_Integer | ActiveOrder () const override |
| virtual const Plate_D2 & | G2Target () const override |
 Public Member Functions inherited from NLPlate_HPG0G1Constraint | |
| NLPlate_HPG0G1Constraint (const gp_XY &UV, const gp_XYZ &Value, const Plate_D1 &D1T) | |
| virtual void | SetOrientation (const Standard_Integer Orient=0) override |
| virtual Standard_Integer | Orientation () override |
| virtual const Plate_D1 & | G1Target () const override |
| Public Member Functions inherited from NLPlate_HPG0Constraint | |
| NLPlate_HPG0Constraint (const gp_XY &UV, const gp_XYZ &Value) | |
| virtual void | SetUVFreeSliding (const Standard_Boolean UVFree) override |
| virtual void | SetIncrementalLoadAllowed (const Standard_Boolean ILA) override |
| virtual Standard_Boolean | UVFreeSliding () const override |
| virtual Standard_Boolean | IncrementalLoadAllowed () const override |
| virtual Standard_Boolean | IsG0 () const override |
| virtual const gp_XYZ & | G0Target () const override |
| Public Member Functions inherited from NLPlate_HGPPConstraint | |
| NLPlate_HGPPConstraint () | |
| virtual void | SetActiveOrder (const Standard_Integer ActiveOrder) |
| virtual void | SetUV (const gp_XY &UV) |
| virtual void | SetG0Criterion (const Standard_Real TolDist) |
| virtual void | SetG1Criterion (const Standard_Real TolAng) |
| virtual void | SetG2Criterion (const Standard_Real TolCurv) |
| virtual void | SetG3Criterion (const Standard_Real TolG3) |
| virtual const gp_XY & | UV () const |
| virtual const Plate_D3 & | G3Target () const |
| virtual Standard_Real | G0Criterion () const |
| virtual Standard_Real | G1Criterion () const |
| virtual Standard_Real | G2Criterion () const |
| virtual Standard_Real | G3Criterion () const |
| Public Member Functions inherited from Standard_Transient | |
| Standard_Transient () | |
| Empty constructor. | |
| Standard_Transient (const Standard_Transient &) | |
| Copy constructor – does nothing. | |
| Standard_Transient & | operator= (const Standard_Transient &) |
| Assignment operator, needed to avoid copying reference counter. | |
| virtual | ~Standard_Transient () |
| Destructor must be virtual. | |
| virtual const opencascade::handle< Standard_Type > & | DynamicType () const |
| Returns a type descriptor about this object. | |
| Standard_Boolean | IsInstance (const opencascade::handle< Standard_Type > &theType) const |
| Returns a true value if this is an instance of Type. | |
| Standard_Boolean | IsInstance (const Standard_CString theTypeName) const |
| Returns a true value if this is an instance of TypeName. | |
| Standard_Boolean | IsKind (const opencascade::handle< Standard_Type > &theType) const |
| Returns true if this is an instance of Type or an instance of any class that inherits from Type. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Boolean | IsKind (const Standard_CString theTypeName) const |
| Returns true if this is an instance of TypeName or an instance of any class that inherits from TypeName. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Transient * | This () const |
| Returns non-const pointer to this object (like const_cast). For protection against creating handle to objects allocated in stack or call from constructor, it will raise exception Standard_ProgramError if reference counter is zero. | |
| Standard_Integer | GetRefCount () const noexcept |
| Get the reference counter of this object. | |
| void | IncrementRefCounter () noexcept |
| Increments the reference counter of this object. | |
| Standard_Integer | DecrementRefCounter () noexcept |
| Decrements the reference counter of this object; returns the decremented value. | |
| virtual void | Delete () const |
| Memory deallocator for transient classes. | |
Additional Inherited Members | |
| typedef void | base_type |
| Returns a type descriptor about this object. | |
| static constexpr const char * | get_type_name () |
| Returns a type descriptor about this object. | |
| static const opencascade::handle< Standard_Type > & | get_type_descriptor () |
| Returns type descriptor of Standard_Transient class. | |
| Protected Attributes inherited from NLPlate_HGPPConstraint | |
| gp_XY | myUV |
| Standard_Integer | myActiveOrder |
define a PinPoint G0+G2 Constraint used to load a Non Linear Plate
| NLPlate_HPG0G2Constraint::NLPlate_HPG0G2Constraint | ( | const gp_XY & | UV, |
| const gp_XYZ & | Value, | ||
| const Plate_D1 & | D1T, | ||
| const Plate_D2 & | D2T ) |
|
overridevirtual |
Reimplemented from NLPlate_HPG0G1Constraint.
Reimplemented in NLPlate_HPG0G3Constraint.
|
overridevirtual |
Reimplemented from NLPlate_HGPPConstraint.
