1.13.2 Index buffer is just a VBO with special target (GL_ELEMENT_ARRAY_BUFFER). More...
#include <OpenGl_IndexBuffer.hxx>
Public Member Functions | |
| OpenGl_IndexBuffer () | |
| Empty constructor. | |
| virtual unsigned int | GetTarget () const override |
| Return buffer object target (GL_ELEMENT_ARRAY_BUFFER). | |
| virtual void | DumpJson (Standard_OStream &theOStream, Standard_Integer theDepth=-1) const override |
| Dumps the content of me into the stream. | |
 Public Member Functions inherited from OpenGl_Buffer | |
| OpenGl_Buffer () | |
| Create uninitialized buffer. | |
| virtual | ~OpenGl_Buffer () |
| Destroy object. | |
| virtual bool | IsVirtual () const |
| Return TRUE if this is a virtual (for backward compatibility) VBO object. | |
| bool | IsValid () const |
| unsigned int | GetComponentsNb () const |
| Standard_Integer | GetElemsNb () const |
| void | SetElemsNb (Standard_Integer theNbElems) |
| Overrides the number of vertex attributes / number of vertexes. It is up to user specifying this number correct (e.g. below initial value)! | |
| unsigned int | GetDataType () const |
| Standard_Byte * | GetDataOffset () const |
| virtual bool | Create (const Handle< OpenGl_Context > &theGlCtx) |
| Creates buffer object name (id) if not yet generated. Data should be initialized by another method. | |
| virtual void | Release (OpenGl_Context *theGlCtx) override |
| Destroy object - will release GPU memory if any. | |
| virtual void | Bind (const Handle< OpenGl_Context > &theGlCtx) const |
| Bind this buffer object. | |
| virtual void | Unbind (const Handle< OpenGl_Context > &theGlCtx) const |
| Unbind this buffer object. | |
| bool | Init (const Handle< OpenGl_Context > &theGlCtx, const unsigned int theComponentsNb, const Standard_Integer theElemsNb, const float *theData) |
| Notice that buffer object will be unbound after this call. | |
| bool | Init (const Handle< OpenGl_Context > &theGlCtx, const unsigned int theComponentsNb, const Standard_Integer theElemsNb, const unsigned int *theData) |
| Notice that buffer object will be unbound after this call. | |
| bool | Init (const Handle< OpenGl_Context > &theGlCtx, const unsigned int theComponentsNb, const Standard_Integer theElemsNb, const unsigned short *theData) |
| Notice that buffer object will be unbound after this call. | |
| bool | Init (const Handle< OpenGl_Context > &theGlCtx, const unsigned int theComponentsNb, const Standard_Integer theElemsNb, const Standard_Byte *theData) |
| Notice that buffer object will be unbound after this call. | |
| bool | SubData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, const float *theData) |
| Notice that buffer object will be unbound after this call. Function replaces portion of data within this buffer object using glBufferSubData(). The buffer object should be initialized before call. | |
| bool | GetSubData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, float *theData) |
| Read back buffer sub-range. Notice that buffer object will be unbound after this call. Function reads portion of data from this buffer object using glGetBufferSubData(). | |
| bool | SubData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, const unsigned int *theData) |
| Notice that buffer object will be unbound after this call. Function replaces portion of data within this buffer object using glBufferSubData(). The buffer object should be initialized before call. | |
| bool | GetSubData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, unsigned int *theData) |
| Read back buffer sub-range. Notice that buffer object will be unbound after this call. Function reads portion of data from this buffer object using glGetBufferSubData(). | |
| bool | SubData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, const unsigned short *theData) |
| Notice that buffer object will be unbound after this call. Function replaces portion of data within this buffer object using glBufferSubData(). The buffer object should be initialized before call. | |
| bool | GetSubData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, unsigned short *theData) |
| Read back buffer sub-range. Notice that buffer object will be unbound after this call. Function reads portion of data from this buffer object using glGetBufferSubData(). | |
| bool | SubData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, const Standard_Byte *theData) |
| Notice that buffer object will be unbound after this call. Function replaces portion of data within this buffer object using glBufferSubData(). The buffer object should be initialized before call. | |
| bool | GetSubData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, Standard_Byte *theData) |
| Read back buffer sub-range. Notice that buffer object will be unbound after this call. Function reads portion of data from this buffer object using glGetBufferSubData(). | |
| virtual Standard_Size | EstimatedDataSize () const override |
| offset to data | |
| virtual bool | init (const Handle< OpenGl_Context > &theGlCtx, const unsigned int theComponentsNb, const Standard_Integer theElemsNb, const void *theData, const unsigned int theDataType, const Standard_Integer theStride) |
| Initialize buffer with new data. | |
| bool | init (const Handle< OpenGl_Context > &theGlCtx, const unsigned int theComponentsNb, const Standard_Integer theElemsNb, const void *theData, const unsigned int theDataType) |
| Initialize buffer with new data. | |
| virtual bool | subData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, const void *theData, const unsigned int theDataType) |
| Update part of the buffer with new data. | |
| virtual bool | getSubData (const Handle< OpenGl_Context > &theGlCtx, const Standard_Integer theElemFrom, const Standard_Integer theElemsNb, void *theData, const unsigned int theDataType) |
| Read back buffer sub-range. | |
| Public Member Functions inherited from OpenGl_Resource | |
| OpenGl_Resource () | |
| Empty constructor. | |
| virtual | ~OpenGl_Resource () |
| Destructor. Inheritors should call Clean (NULL) within it. | |
| Public Member Functions inherited from Standard_Transient | |
| Standard_Transient () | |
| Empty constructor. | |
| Standard_Transient (const Standard_Transient &) | |
| Copy constructor – does nothing. | |
| Standard_Transient & | operator= (const Standard_Transient &) |
| Assignment operator, needed to avoid copying reference counter. | |
| virtual | ~Standard_Transient () |
| Destructor must be virtual. | |
| virtual const opencascade::handle< Standard_Type > & | DynamicType () const |
| Returns a type descriptor about this object. | |
| Standard_Boolean | IsInstance (const opencascade::handle< Standard_Type > &theType) const |
| Returns a true value if this is an instance of Type. | |
| Standard_Boolean | IsInstance (const Standard_CString theTypeName) const |
| Returns a true value if this is an instance of TypeName. | |
| Standard_Boolean | IsKind (const opencascade::handle< Standard_Type > &theType) const |
| Returns true if this is an instance of Type or an instance of any class that inherits from Type. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Boolean | IsKind (const Standard_CString theTypeName) const |
| Returns true if this is an instance of TypeName or an instance of any class that inherits from TypeName. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Transient * | This () const |
| Returns non-const pointer to this object (like const_cast). For protection against creating handle to objects allocated in stack or call from constructor, it will raise exception Standard_ProgramError if reference counter is zero. | |
| Standard_Integer | GetRefCount () const noexcept |
| Get the reference counter of this object. | |
| void | IncrementRefCounter () noexcept |
| Increments the reference counter of this object. | |
| Standard_Integer | DecrementRefCounter () noexcept |
| Decrements the reference counter of this object; returns the decremented value. | |
| virtual void | Delete () const |
| Memory deallocator for transient classes. | |
Additional Inherited Members | |
| typedef void | base_type |
| Returns a type descriptor about this object. | |
| Static Public Member Functions inherited from OpenGl_Buffer | |
| static TCollection_AsciiString | FormatTarget (unsigned int theTarget) |
| Format VBO target enumeration value. | |
| static size_t | sizeOfGlType (unsigned int theType) |
| static constexpr const char * | get_type_name () |
| Returns a type descriptor about this object. | |
| static const opencascade::handle< Standard_Type > & | get_type_descriptor () |
| Returns type descriptor of Standard_Transient class. | |
| Static Public Attributes inherited from OpenGl_Buffer | |
| static const unsigned int | NO_BUFFER = 0 |
| Helpful constants. | |
| void | BindBufferBase (const Handle< OpenGl_Context > &theGlCtx, unsigned int theIndex) |
| Binds a buffer object to an indexed buffer target. Wrapper for glBindBufferBase(). | |
| void | UnbindBufferBase (const Handle< OpenGl_Context > &theGlCtx, unsigned int theIndex) |
| Unbinds a buffer object from an indexed buffer target. Wrapper for glBindBufferBase(). | |
| void | BindBufferRange (const Handle< OpenGl_Context > &theGlCtx, unsigned int theIndex, const intptr_t theOffset, const size_t theSize) |
| Binds a buffer object to an indexed buffer target with specified offset and size. Wrapper for glBindBufferRange(). | |
| Standard_Byte * | myOffset |
| offset to data | |
| unsigned int | myBufferId |
| VBO name (index) | |
| unsigned int | myComponentsNb |
| Number of components per generic vertex attribute, must be 1, 2, 3, or 4. | |
| Standard_Integer | myElemsNb |
| Number of vertex attributes / number of vertices. | |
| unsigned int | myDataType |
| Data type (GL_FLOAT, GL_UNSIGNED_INT, GL_UNSIGNED_BYTE etc.) | |
Index buffer is just a VBO with special target (GL_ELEMENT_ARRAY_BUFFER).
| OpenGl_IndexBuffer::OpenGl_IndexBuffer | ( | ) |
Empty constructor.
|
overridevirtual |
Dumps the content of me into the stream.
Reimplemented from OpenGl_Buffer.
|
overridevirtual |
Return buffer object target (GL_ELEMENT_ARRAY_BUFFER).
Implements OpenGl_Buffer.
