1.13.2 Representation of STEP entity FeaAxis2Placement3d. More...
#include <StepFEA_FeaAxis2Placement3d.hxx>
Public Member Functions | |
| StepFEA_FeaAxis2Placement3d () | |
| Empty constructor. | |
| void | Init (const Handle< TCollection_HAsciiString > &aRepresentationItem_Name, const Handle< StepGeom_CartesianPoint > &aPlacement_Location, const Standard_Boolean hasAxis2Placement3d_Axis, const Handle< StepGeom_Direction > &aAxis2Placement3d_Axis, const Standard_Boolean hasAxis2Placement3d_RefDirection, const Handle< StepGeom_Direction > &aAxis2Placement3d_RefDirection, const StepFEA_CoordinateSystemType aSystemType, const Handle< TCollection_HAsciiString > &aDescription) |
| Initialize all fields (own and inherited) | |
| StepFEA_CoordinateSystemType | SystemType () const |
| Returns field SystemType. | |
| void | SetSystemType (const StepFEA_CoordinateSystemType SystemType) |
| Set field SystemType. | |
| Handle< TCollection_HAsciiString > | Description () const |
| Returns field Description. | |
| void | SetDescription (const Handle< TCollection_HAsciiString > &Description) |
| Set field Description. | |
 Public Member Functions inherited from StepGeom_Axis2Placement3d | |
| StepGeom_Axis2Placement3d () | |
| Returns a Axis2Placement3d. | |
| void | Init (const Handle< TCollection_HAsciiString > &aName, const Handle< StepGeom_CartesianPoint > &aLocation, const Standard_Boolean hasAaxis, const Handle< StepGeom_Direction > &aAxis, const Standard_Boolean hasArefDirection, const Handle< StepGeom_Direction > &aRefDirection) |
| void | SetAxis (const Handle< StepGeom_Direction > &aAxis) |
| void | UnSetAxis () |
| Handle< StepGeom_Direction > | Axis () const |
| Standard_Boolean | HasAxis () const |
| void | SetRefDirection (const Handle< StepGeom_Direction > &aRefDirection) |
| void | UnSetRefDirection () |
| Handle< StepGeom_Direction > | RefDirection () const |
| Standard_Boolean | HasRefDirection () const |
| Public Member Functions inherited from StepGeom_Placement | |
| StepGeom_Placement () | |
| Returns a Placement. | |
| void | Init (const Handle< TCollection_HAsciiString > &aName, const Handle< StepGeom_CartesianPoint > &aLocation) |
| void | SetLocation (const Handle< StepGeom_CartesianPoint > &aLocation) |
| Handle< StepGeom_CartesianPoint > | Location () const |
| Public Member Functions inherited from StepGeom_GeometricRepresentationItem | |
| StepGeom_GeometricRepresentationItem () | |
| Returns a GeometricRepresentationItem. | |
| Public Member Functions inherited from StepRepr_RepresentationItem | |
| StepRepr_RepresentationItem () | |
| Returns a RepresentationItem. | |
| void | Init (const Handle< TCollection_HAsciiString > &aName) |
| void | SetName (const Handle< TCollection_HAsciiString > &aName) |
| Handle< TCollection_HAsciiString > | Name () const |
| Public Member Functions inherited from Standard_Transient | |
| Standard_Transient () | |
| Empty constructor. | |
| Standard_Transient (const Standard_Transient &) | |
| Copy constructor – does nothing. | |
| Standard_Transient & | operator= (const Standard_Transient &) |
| Assignment operator, needed to avoid copying reference counter. | |
| virtual | ~Standard_Transient () |
| Destructor must be virtual. | |
| virtual const opencascade::handle< Standard_Type > & | DynamicType () const |
| Returns a type descriptor about this object. | |
| Standard_Boolean | IsInstance (const opencascade::handle< Standard_Type > &theType) const |
| Returns a true value if this is an instance of Type. | |
| Standard_Boolean | IsInstance (const Standard_CString theTypeName) const |
| Returns a true value if this is an instance of TypeName. | |
| Standard_Boolean | IsKind (const opencascade::handle< Standard_Type > &theType) const |
| Returns true if this is an instance of Type or an instance of any class that inherits from Type. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Boolean | IsKind (const Standard_CString theTypeName) const |
| Returns true if this is an instance of TypeName or an instance of any class that inherits from TypeName. Note that multiple inheritance is not supported by OCCT RTTI mechanism. | |
| Standard_Transient * | This () const |
| Returns non-const pointer to this object (like const_cast). For protection against creating handle to objects allocated in stack or call from constructor, it will raise exception Standard_ProgramError if reference counter is zero. | |
| Standard_Integer | GetRefCount () const noexcept |
| Get the reference counter of this object. | |
| void | IncrementRefCounter () noexcept |
| Increments the reference counter of this object. | |
| Standard_Integer | DecrementRefCounter () noexcept |
| Decrements the reference counter of this object; returns the decremented value. | |
| virtual void | Delete () const |
| Memory deallocator for transient classes. | |
Additional Inherited Members | |
| typedef void | base_type |
| Returns a type descriptor about this object. | |
| static constexpr const char * | get_type_name () |
| Returns a type descriptor about this object. | |
| static const opencascade::handle< Standard_Type > & | get_type_descriptor () |
| Returns type descriptor of Standard_Transient class. | |
Representation of STEP entity FeaAxis2Placement3d.
| StepFEA_FeaAxis2Placement3d::StepFEA_FeaAxis2Placement3d | ( | ) |
Empty constructor.
| Handle< TCollection_HAsciiString > StepFEA_FeaAxis2Placement3d::Description | ( | ) | const |
Returns field Description.
| void StepFEA_FeaAxis2Placement3d::Init | ( | const Handle< TCollection_HAsciiString > & | aRepresentationItem_Name, |
| const Handle< StepGeom_CartesianPoint > & | aPlacement_Location, | ||
| const Standard_Boolean | hasAxis2Placement3d_Axis, | ||
| const Handle< StepGeom_Direction > & | aAxis2Placement3d_Axis, | ||
| const Standard_Boolean | hasAxis2Placement3d_RefDirection, | ||
| const Handle< StepGeom_Direction > & | aAxis2Placement3d_RefDirection, | ||
| const StepFEA_CoordinateSystemType | aSystemType, | ||
| const Handle< TCollection_HAsciiString > & | aDescription ) |
Initialize all fields (own and inherited)
| void StepFEA_FeaAxis2Placement3d::SetDescription | ( | const Handle< TCollection_HAsciiString > & | Description | ) |
Set field Description.
| void StepFEA_FeaAxis2Placement3d::SetSystemType | ( | const StepFEA_CoordinateSystemType | SystemType | ) |
Set field SystemType.
| StepFEA_CoordinateSystemType StepFEA_FeaAxis2Placement3d::SystemType | ( | ) | const |
Returns field SystemType.
